HOQS Type "O" Paraflex CRAM! 2x12 V2 subwoofer tuned in the mid 30s
V2 Update
The
PARAFLEX OCRAM 2x12 V2 Update resolves the previous amplitude response
dip at 130Hz and improves frequency and phase response to an extended
frequency of 180Hz
This
fine tuning requires extra care to be taken if using a grille, making
the CSA of the mouth any smaller will affect performance, calculate your
surface area loss and apply it back to the mouth before covering with a
grille. eg: 75% open area will remove 25%, adjust the lower plank width
accordingly to maintain the designed CSA
Compact
with outer dimensions of 1000*368*678mm yet highly potent with fully
respectable power density, output capability, and bandwidth when loaded
with the recommended drivers
Operating Specs
Fb: 37Hz
Operating Range: 35Hz-100Hz
Sensitivity: 35Hz-100Hz: 102dB avg 1w@1m
Maximum SPL: 132dB continuous 138dB Peak
Design Specs
Size - Length x Width x Height:
39.4" x 27" x 14.5" (1000mm x 687mm x 368mm)
Volume: 253 Litres
Weight: 81.5 Lbs (37 Kg)
